| Target Gas | O2 |
| Measuring Range | 0 - 100% O2 |
| LDL | PPM sensors | N/A |
| Published Signal Output in air (1) | 28 - 45 mV |
| Response Time T90% | 9 S |
| Accuracy Full Scale (2) | 0.02 |
| Drift % Signal Month (2) | < 1% |
| Linearity (2) | 0.01 |
| Humidity Non-Condensing | 0-99% RH |
| Temperature Coefficient | Non-Compensated |
| Operating Temperature | 0-45° C |
| Storage Temperature | 0-40° C |
| Operating Pressure | Consistent 5-30 PSIG |
| Flow Rate | .1-10 LPM |
| Expected Life (1) | 60 Months |
| Storage / Shelf life (4) | < 6 Months |
| Warranty (5) | 18 Months |
| Connector Type | 3 Ring |
| Gas Connection | O-Ring |
| Housing Material | Delren |
| FDA | Yes |
| CE | Yes |
| MDSAP ISO13485: 2016 | Yes |
| ISO9001:2015 | Yes |
| Sensor Technology | Echem |
Specifications validated during design and in the pursuit of improvement are subject along with prices to change without notice.
(1) In air (20.9% oxygen) at 25º C and 1 atm. Expected life varies inversely with changes in O2 concentration, temperature, pressure.
(2) Under constant conditions. Calibrate as near sample conditions as possible. Calibrate with 95-100% oxygen for measurements > 40% oxygen.
(3) Once the signal output stabilizes following a step change in temperature.
(4) Recommended 0-40° C. Sensors may be stored at -10 to 55° C on an intermittent basis only
(5) Ex-Factory unless otherwise agreed to in writing. Under normal operating conditions for medical oxygen delivery equipment the sensors are warranted to be free of defects in materials and workmanship for the specified period above provided the sensor is properly installed and operated. The sole remedy for a sensor determined to be defective by Analytical Industries Inc. is limited to replacing the defective sensor. Analytical Industries Inc. shall not be liable for buyer’s negligence, misapplication, alteration, abuse or accident.
Specification validated during design and in pursuit of improvement are subject to change without notice.
